Facades
FSX 110 SSG Structurally Silicone Glazed (SSG) Curtain Wall System
Building on the advantages of Novastruct's FSX 110 65mm Curtain Wall System, FSX 110 SSG can help you to achieve your highest facade performance and aesthetic aspirations.
Product overview
The system can also accommodate +/- 5mm differential vertical movement between the facade and supporting sub-structure.
With a seamless, prestige silicone weatherproof seal finish, FSX 110 SSG eliminates conventional pressure plates and face caps to further enhance the system’s impressive aesthetics.
Available in a range of glazing thicknesses and with a triple glazing option, the system can further enhance design versatility and specification demands on commercial, public, education, healthcare, residential and logistical projects.
Novastruct’s full support team are always available to assist you in fine tuning FSX 110 SSG to fully meet your exacting project goals.
Product details
Technical details
Performance
Key features
Features
FSX 110 SSG can achieve a Uf value as low as 0.83 W/m²K
Independently tested weather performance
- Windload 2400Pa
- Air Permeability 600Pa
- Watertightness 600Pa
Tested to EN 1627 RC2 (Resistance Class 2)
Available in a range of window depth and glazing thickness options to suit your project:
- System width – 50mm
- System depth – 65mm – 275mm
- Glazing thickness – 4mm – 58mm
- Glazing from 30mm to 58mm
- Integration with both FSX 100 and FSX 110 curtain wall systems
- Triple-glazed option
- New enhanced movement joint
Novastruct curtain walling uses simple materials that maximise the opportunity for reuse and recycling at their end of life.
Frame materials are 100% recyclable and extruded aluminium includes more than 75% recycled content.
Additional information
Proven Performance
Backed by CWCT Sequence B testing and certification, FSX 110 SSG has a long-term track record on a wide range of projects.
Design Flexibility
Maximised structural capability and design with a range of mullions and transoms
Proven performance
