Facades
FSX 110 65mm Curtain Wall System
Novastruct's FSX 110 65mm Curtain Wall System offers outstanding looks, project flexibility and optimum long-term performance and can also achieve floor slab live load deflection of +/-15mm.
Product overview
FSX 110 provides high-level weathertightness and is a cost-effective solution for barrier loading.
Thermal break options can be tuned to precisely match the most exacting project requirements on a wide application palette, including commercial, public, education, healthcare, residential and logistical buildings.
As with every Novastruct system, we are with you all the way to help you realise your most ambitious facade aspirations.
Product details
Technical details
Performance
Key features
Features
FSX 110 can achieve a Uf value as low as 2.36 W/m²K
Independently tested weather performance
- Windload 2400Pa
- Air Permeability 600Pa
- Watertightness 600Pa
Tested to EN 1627 RC2 (Resistance Class 2)
Available in a range of window depth and glazing thickness options to suit your project:
- System width – 65mm
- System depth – 65mm – 275mm
- Glazing thickness – 4mm – 50mm
- Range of mullion, transom and face cap options with 65mm sightlines
- Facilitates the integration of opening window products including a concealed vent option
- Offers a cost effective solution for barrier loading
- Floor slab live load deflection of +/- 15mm is achievable
Novastruct curtain walling uses simple materials that maximise the opportunity for reuse and recycling at their end of life.
Frame materials are 100% recyclable and extruded aluminium includes more than 75% recycled content.
Additional information
Proven Performance
Backed by CWCT Sequence B testing and certification, FSX 110 has a long-term track record on a wide range of projects.
Design Flexibility
A comprehensive range of mullions and transoms allow façades to be designed with minimal structural support
Proven performance
