FSX 100 SSG Structurally Silicone Glazed (SSG) Curtain Wall System
FSX 100 Structurally Silicone Glazed (SSG) combines established Novastruct curtain walling high-performance with sleek, seamless aesthetics for optimal facade design and uncompromised structural capabilities.
Product overview
Offering a flush exterior glazing appearance using a UV-resistant silicone-sealed glass-to-glass joint, FSX 100 SSG can be triple-glazed in a variety of glazing thicknesses, maximizing design flexibility and great looks.
FSX 100 SSG allows specifiers to be highly creative with the verified additional assurance of weathertightness and occupant comfort on the most prestigious projects or almost any application where exceptional appearance and high-level specification is paramount.
Backed by Novastruct’s full technical support every step of the way.
Product details
Technical details
Performance
Key features
Features
FSX 100 SSG can achieve a Uf value as low as 0.93 W/m²K
Independently tested weather performance
- Windload 2400Pa
- Air Permeability 600Pa
- Watertightness 600Pa
Tested to EN 1627 RC2 (Resistance Class 2)
Available in a range of window depth and glazing thickness options to suit your project:
- System width – 50mm
- System depth – 65mm – 275mm
- Glazing thickness – 4mm – 58mm
- Glazing from 30mm to 58mm for increased design flexibility
- Maximised structural capability and design with a range of mullions and transoms
- Integration with both FSX 100 and FSX 110 curtain wall systems
- Can accommodate triple glazing retained using a toggle system
Novastruct curtain walling uses simple materials that maximise the opportunity for reuse and recycling at their end of life.
Frame materials are 100% recyclable and extruded aluminium includes more than 75% recycled content.
Additional information
Proven Performance
Backed by CWCT Sequence B testing and certification, FSX 100 SSG has a long-term track record on a wide range of projects.
Design Flexibility
FSX 100 SSG offers a range of glazing options, mullions and transoms to suit the application
