FSX 100 50mm Curtain Wall System
The FSX 100 is a precision-engineered stick-frame system designed to balance aesthetics with ease of installation. Suitable for vertical, sloped, or faceted applications, it offers a variety of capping and thermal options to suit any project requirement.
Product overview
Novastruct’s FSX 100 50mm Curtain Wall System offers designers a project-proven and versatile canvas to create distinctive high-performance facades.
Using a simple installation method, FSX100 has been tried and tested to provide robust weathering capabilities in a variety of configurations, including vertical and sloped applications, plus faceted walls.
Achieving U values as low as 1.93W/m2K, FSX 100 provides you with a strong blend of technical accomplishment and practical features for wide-ranging applications, including commercial, public, education, healthcare, residential and logistical projects.
FSX 100 is fully backed by Novastruct’s comprehensive support to assist you at every stage of the specification and construction process.
Product details
Technical details
Performance
Key features
Features
FSX 100 can achieve a Uf value as low as 1.93 W/m²K
Independently tested weather performance
- Windload 2400Pa
- Air Permeability 600Pa
- Watertightness 600Pa
Tested to EN 1627 RC2 (Resistance Class 2)
Available in a range of window depth and glazing thickness options to suit your project:
- System width – 50mm
- System depth – 65mm – 275mm
- Glazing thickness – 4mm – 50mm
- Large choice of face caps, including bespoke options, enable design flexibility to suit your individual needs
- Range of mullion, transom and face cap options with 50mm sightlines
- Fire-resistant option
Novastruct curtain walling uses simple materials that maximise the opportunity for reuse and recycling at their end of life.
Frame materials are 100% recyclable and extruded aluminium includes more than 75% recycled content.
Additional information
Proven Performance
Backed by CWCT Sequence B testing and certification, FSX 100 has a long-term track record on a wide range of projects.
Design Flexibility
The FSX 100 HC/VC Horizontal/Vertical Cap facilitates highlighting of horizontal or vertical features across the building envelope to create a highly individual signature.
Fire Resistance
FSX 100 is a fire resistant solution, providing uniformity of the façade in accordance with Pr EN 1364-3, with up to 30 minutes integrity and insulation.
