Aluminium Doors
RT 72 Reflex Aluminium Door
The RT 72 Reflex Aluminium Door System combines strong thermal performance, robust security and refined aluminium aesthetics in one modular, thermally broken platform.
Product overview
With patented Reflex thermal technology, slim profiles, concealed drainage and a wide choice of styling options, RT 72 provides a high-performance door solution for modern building specifications.
Product details
Technical details
Performance
Key features
Configurations
Features
Available in a range of thermal performance levels to suit different project requirements.
Depending on configuration, size and glazing specification, the system can achieve Uw values from 0.96 W/m²K – 1.32 W/m²K using 0.7 and 0.5 Ug glass
The system uses a 35 mm thermal isolator with patented Reflex technology to help enhance overall thermal efficiency.
RT 72 doors have been tested for high levels of weathertightness, achieving Air Permeability Class 4 and Watertightness 7A. maintaining a clean architectural appearance while supporting reliable performance in use.
The modular RT72 platform supports a broad range of door applications and styling and leaf options.
Cradle to Cradle certification.
Additional information
The RT 72 Reflex Aluminium Door System is a thermally broken, modular aluminium system designed to deliver strong thermal performance and excellent weathering in a refined, slim-profile door solution. Developed around Novastruct’s patented Reflex thermal technology, RT 72 doors offer design flexibility across modern commercial, residential and refurbishment applications, while helping specifiers meet increasingly demanding performance requirements.
Proven performance
