FSX 100 HI Curtain Wall System
Novastruct’s FSX 100 HI Curtain Wall System is Passive House certified, delivering an energy efficient and airtight façade that supports timeless, high performing glazed building envelopes and enhanced occupant comfort.
Product overview
Tested and certified to CWCT Sequence B, FSX 100 HI creates a smarter, lower maintenance and environmentally responsive façade, with thermal insulation options that allow precise performance tailoring to achieve U-values as low as 0.8 W/m²K.
FSX 100 HI offers a versatile choice of face caps, fins and design features, allowing the external appearance to be tailored to suit the vision.
Backed by Novastruct’s unrivalled support, FSX 100 HI has been carefully engineered to deliver a seamless curtain wall appearance suitable for commercial, public, education, healthcare, residential and logistics projects.
Product details
Technical details
Performance
Key features
Features
FSX 100 HI can achieve Uf values of 0.8 W/m²K or better.
Independently tested weather performance
- Windload 2400Pa
- Air Permeability 600Pa
- Watertightness 600Pa
Tested to EN 1627 RC2 (Resistance Class 2)
Available in a range of window depth and glazing thickness options to suit your project:
- System width – 50mm
- System depth – 65mm – 275mm
- Glazing thickness – 6mm – 60mm
- Large choice of face caps, including bespoke options, enable design flexibility to suit your individual needs
- Range of mullion, transom and face cap options with 50mm sightlines
Novastruct curtain walling uses simple materials that maximise the opportunity for reuse and recycling at their end of life.
Frame materials are 100% recyclable and extruded aluminium includes more than 75% recycled content.
Additional information
Proven Performance
Backed by CWCT Sequence B testing and certification, FSX 100 HI has a long-term track record on a wide range of projects.
Design Flexibility
Mullion and transom capping options, including a patented transom overlap detail, enable even further aesthetic customization.
